Ducted Split System & Inverter Air Conditioner

Commercial Split System Air Conditioner

• Suitable for most commercial applications
• Large capacity range to suit most applications (from 7 to 71kW)
• Minimum Energy Performance Standards (MEPS) Compliant
• Building Code of Australia (BCA) Compliant
• Australian engineered to meet Australian conditions
  • Operating range of up to 50°C DB for cooling and -10°C DB for heating (for R410a).
  • Operating range of up to 46°C DB for cooling and -10°C DB for heating (for R22).
• High quality two speed outdoor fans supplied as standard
  • medium static option also available
  • Horizontal condenser fan available on some models
• 3 speed indoor fan for direct drive type
• Various Pulley and Belt Drive combinations for Indoor fan available on request
• Innovative design features
  • Louvre hail guard to protect the condenser coil from the elements and mechanical damage
  • Interlaced evaporator coil for full face cooling on 2 stage systems
  • Durable powder coating to minimise corrosion
  • Robust 60-80 micron powder coat paint Salt Spray tested to AS/NZ standards
  • Vertical Air discharge as standard for larger units. Maximizes performance by discharging hot air in summer and cold air in winter, away from the outdoor unit.
  • Reliable Copeland scroll compressor
  • Hanging brackets supplied standard for models sized between 23kW to 40kW
  • In built safety tray and drain
• All Commercial split air conditioners are suitable for connection to 3rd party controls
• Variations available on request. Contact ActronAir^® for more details.
• The ActronAir^® Technical Support team is available to assist you with any enquiries.
• 2 year Commercial Warranty*.
  • Backed up by the ActronAir^® National Service Network to provide you with quick and reliable service when you need it
